Titanium alloy hydraulic jack

This top not only has the function of ordinary weight, but also has the function of stretching,It is also used for steel cables, cables, and shafts.The piston part and the inner side of the guide cap adopt copper welding process,The surface of the piston rod is plated with hard chromium, and the cylinder is not pulled, which has strong wear resistance

  • Features

Widely used in transportation, railways, bridges, shipbuilding, construction,

Equipment jacking installation, commissioning, maintenance, underground pipe jacking and other operations for industrial and mining enterprises.


  • Parameters


Model

Tonnage

Stroke

Body height

Stretch height

Cylinder area

Cylinder volume

Outer diameter

Weight

BXG-10

10

38

88

126

14.4

55

70

4.1

BXG-20

20

45

98

143

28.6

129

92

5.0

BXG-30

30

60

117

177

41.9

261

102

6.8

BXG-50

50

60

122

182

62.1

373

128

10.9

BXG-100

100

56

141

197

126.9

723

178

22.7

BXG-150

150

56

160

216

254.3

1424

219

49.3

BXG-200

200

56

168

224

314.0

1758

271

65.6


  • Programme


Two-way ultra-high pressure electric pump set

Features: The double-acting large-tonnage jack has large output and strong carrying capacity, and can be operated at a long distance in any space position

Uses: used in transportation, railways, bridges, shipbuilding, construction, mining and other industries





Ultra high pressure solenoid valve electric set (customized with wheels)

Features: The double-acting large-tonnage jack has a large output force and a strong bearing capacity. It can be operated at a long distance in any space position, and it can be moved, fast and convenient.

Uses: used in transportation, railways, bridges, shipbuilding, construction, mining and other industries
