Bidirectional high pressure electric pump

Electric pump station is composed of high and low oil pump, control valve, motor, instrument, reversing valve and oil tank.Power device. The pump station can realize high and low-pressure oil supply at the same time, output large flow, low-pressure pump automatic no-load oil return under high-pressure, reduce motor power loss, and have the performance of shutdown pressure maintaining and reversing.


  • Features


1. All copper motor

2. Bass running

3. Strong power

4. Tailor-made


  • Parameters

model

preset pressure/MPA

Limited Data/MIN

Motor Power
KW

Fuel tank capacity
L

High pressure

Low pressure

High pressure flow

Low pressure flow

DYB0.7/2.4M

80

6.3

0.7L/MIN

2.4L/MIN

1.5

15

DYB0.7/2.4L

63

6.3

0.7L/MIN

2.4L/MIN

0.75

15

DYB1.0/6L

63

4

1.0L/MIN

6L/MIN

1.5

30,40,60

DYB2.4/9L

63

4

2.4L/MIN

9L/MIN

2.2

40,60

DYB3.0/9L

63

4

3.0L/MIN

9L/MIN

3

40,60

DYB4.0/9L

63

4

4.0L/MIN

9L/MIN

4

40,60

DYB6.0/9L

63

4

6.0L/MIN

9L/MIN

5.5

90,120

DYB7.0/9L

63

4

7.0L/MIN

9L/MIN

7.5

90,120

DYB11/23L

63

4

11L/MIN

23L/MIN

11

160,200,300

DYB15/23L

63

4

15L/MIN

23L/MIN

15

160,200,300

  • Programme


Double acting hydraulic jack electric set

Features: This hydraulic electric pump provides oil with dual circuits, which is convenient and quick to avoid slow

spring return and non-synchronization. The product design has high and low pressure two-break type, fast oil output,

fast speed, high efficiency and high pressure; the use of pressure gauge overload protection device can avoid overload

damage.

uses: It can be equipped with oil cylinders or special machines, which can realize the requirements of lifting, bending,

extrusion, shearing, riveting, disassembly, and pressing.





Double hydraulic torque wrench electric pump set

Features: The hydraulic electric pump has dual-circuit oil supply, which is convenient and quick to avoid slow spring

return and non-synchronization. The product design has high and low pressure two-break type, fast oil output, high

speed, high efficiency, and high pressure; adopts The pressure gauge overload protection device can avoid overload

damage.

Uses: It can be equipped with oil cylinders or special machines, which can meet the requirements of lifting, bending,

extrusion,shearing, riveting, disassembly, and pressing.
