One-way high pressure electric hydraulic pump

DSD one-way high-pressure electric hydraulic oil pump is an independent and complete hydraulic power unit composed of axial piston pump (high-pressure pump), low-pressure gear pump, control valve, oil tank, motor, instrument, etc.


  • Features

1. Small size, light weight, easy to use and high working pressure.

2. Single-stage pumping station: simple structure, higher working pressure can be obtained.

3. Pressure maintaining function: If there is no leakage in the external oil circuit, stop the pump to maintain the pressure for 5 minutes, and the rated pressure will not drop more than 0.5Mpa.



  • Parameters

Parameter model

Work pressure/Mpa

High pressure flow/(L/min)

Low pressure flow(L/min)

Motor Power

ZB-0.75

63

0.27

1

0.75

ZB-1.5

63

1

6

1.5

ZB-3.0

63

1.5

7

3

ZB-4.0

63

2

8

4

ZB-5.5

63

4

10

5.5

ZB-7.5

63

6

12

7.5


  • Programme




Single-acting hydraulic jack electric set

Features: 1. Small size, light weight, easy to use, and high working pressure.

2. Single-stage pumping station: simple structure, higher working pressure can be obtained.

3. Pressure maintaining function: When there is no leakage in the external oil circuit, the rated

pressure drop of no more than0.5Mpa after stopping the pump to maintain the pressure for 5 minutes.

Uses: 1. Equipped with oil cylinders or special machines, it can realize lifting, bending, straightening, extrusion, shearing, riveting, disassembly, pressing and other work requirements.

2. The device is used as a hydraulic power source in some mechanical equipment.

3. As a pressure test pump station for various high-pressure hydraulic components, high-pressure containers, and high-pressure hoses.
