The electric pump is a hydraulic power unit composed of high and low pressure oil pumps, control valves, motors, instruments, reversing valves, and oil tanks.
Lightweight, low energy consumption, high pressure, high efficiency, all-copper motor, cast iron housing, integrated structure, strong power.
|
Parameter model |
High pressure/Mpa |
High pressure flow/L/min |
Low pressure flow/L/min |
Motor Power/KW |
|
QX-0.75 |
63 |
0.27 |
1 |
0.75 |
|
QX-1.5 |
63 |
1 |
6 |
1.5 |
|
QX-3.0 |
63 |
1.5 |
7 |
3 |
|
QX-4.0 |
63 |
2 |
8 |
4 |
|
QX-5.5 |
63 |
4 |
10 |
5.5 |
|
QX-7.5 |
63 |
6 |
12 |
7.5 |
