Bearing heater HA

The magnetic field generated by the coil through electromagnetic induction generates a large amount of current inside the workpiece, which is converted into heat. High voltage and low current pass through the induction coil with a large number of turns, and low voltage and high current are generated on the workpiece.


  • Features

Apply a layer of general bearing grease to the contact surface of the horizontal and vertical yoke, which not only reduces the magnetic field loss, but also significantly reduces the noise level.


  • Parameters

Model

HA-1

HA-2

HA-2A

HA-3

HA-4

HA-5

HA-6

Rated power KVA

2.2

3.3

3.3

5.5

9

12

14

Rated voltage V

220

220

220

380

380

380

380

Rated current A

10

12

12

15

20

30

135

way to control

Manual control, temperature control, time control

Maximum heating temperature

300℃

300℃

300℃

300℃

300℃

300℃

300℃

Heating the workpiece

the inside diameter of

Φ30-70

Φ70-140

Φ30-100

Φ100-200

Φ60-250

Φ80-360

Φ180-400

Outer diameter

<Φ250

<Φ360

<Φ360

<Φ440

<Φ480

<Φ510

<Φ530

Width

110

110

110

140

180

200

220

Weight

29

31

35

63

76

98

118

Heating rod size

20×20
40×40

30×30
50×50

30×30
50×50
50×50

40×40
60×60

40×40
70×70

40×40
70×70

50×50
80×80




  • Programme
