The magnetic field generated by the coil through electromagnetic induction generates a large amount of current inside the workpiece, which is converted into heat. High voltage and low current pass through the induction coil with a large number of turns, and low voltage and high current are generated on the workpiece
Apply a layer of general bearing grease to the contact surface of the horizontal and vertical yoke, which not only reduces the magnetic field loss, but also significantly reduces the noise level
|
Model |
20X-1 |
20X-2 |
20X-3 |
20X-4 |
20X-5 |
|
|
rated power |
2.2KVA |
5.5KVA |
7.5KVA |
11KVA |
13KVA |
|
|
Rated voltage |
220V |
380VTwo-phase |
380VTwo-phase |
380VTwo-phase |
380VTwo-phase |
|
|
Heating the workpiece |
the inside diameter of |
30-85mm |
85-160mm |
120-250mm |
150-360mm |
180-400mm |
|
Outer diameter |
280mm |
350mm |
400mm |
450mm |
500mm |
|
|
width |
100mm |
150mm |
180mm |
200mm |
220mm |
|
|
Weight |
36kg |
105kg |
120kg |
135kg |
150kg |
|
