The magnetic field generated by the coil through electromagnetic induction generates a large amount of current inside the workpiece, which is converted into heat. High voltage and low current pass through the induction coil with a large number of turns, and low voltage and high current are generated on the workpiece
Apply a layer of general bearing grease to the contact surface of the horizontal and vertical yoke, which not only reduces the magnetic field loss, but also significantly reduces the noise level
|
Model |
YLGD-20 |
YLGD-60 |
YLGD-75 |
YLGD-120 |
|
Rated power KVA |
20 |
60 |
75 |
120 |
|
Voltage |
380VTwo-phase |
380VTwo-phase |
380VTwo-phase |
380VTwo-phase |
|
Current A |
60 |
160 |
188 |
188 |
|
Maximum heating time |
9995 |
9995 |
9995 |
9995 |
|
Workpiece outer diameter mm |
600 |
800 |
1000 |
1300 |
|
Bearing inner diameter mm |
150-400 |
180-600 |
210-800 |
400-1000 |
|
Bearing width mm |
300 |
400 |
520 |
580 |
