The hydraulic anti-skid puller is driven by manual or electric pump. The large piston of the main body of the pull horse moves forward directly through the transmission of high-pressure oil pipe, so the push rod itself does not rotate. The hook and claw seat can adjust the distance of forward and backward directly with the screw thread. During operation, as long as the handle swings slightly before and after, and the oil pressure starting rod moves forward, the hook claw moves backward correspondingly, and the pulled object is pulled out.
1. Alloy forging
2. Strong and durable
3. Complete tonnage
4. Disassembly tools
|
Model |
Number of claws |
Disassembly length |
Contribute mm |
Demolition diameter |
weight/kg |
Center bolt diameter |
|
EP-204 |
2 |
101 |
2 |
12-127 |
1.4 |
14 |
|
EP-104 |
3 |
101 |
5 |
12-127 |
1.8 |
14 |
|
EP-206 |
2 |
152 |
6 |
12-178 |
3.2 |
16 |
|
EP-106 |
3 |
152 |
10 |
12-178 |
3.6 |
16 |
|
EP-208 |
2 |
203 |
12 |
19-304 |
5.4 |
20 |
|
EP-108 |
3 |
245 |
17 |
19-304 |
6.4 |
20 |
|
EP-210 |
2 |
245 |
14 |
25-381 |
5.9 |
20 |
|
EP-110 |
3 |
304 |
20 |
25-381 |
7.3 |
20 |
|
EP-213 |
2 |
304 |
25 |
63-457 |
17.2 |
29 |
|
EP-113 |
3 |
304 |
30 |
63-457 |
20.0 |
29 |
|
EP-216 |
2 |
355 |
35 |
76-635 |
25.8 |
31 |
|
EP-116 |
3 |
355 |
40 |
76-635 |
30.8 |
31 |
