MDS torque amplifier wrench

The torque multiplier is composed of a circular or planetary gear combined in different combination layers to drive the gear to rotate and output. In the planetary gear system, the torque is input and output through the sun gear. The rotation is driven by the combination of three or four planetary gears and the sun gear. The circumferential gear in the multiplier housing is engaged with the surrounding inner planetary gear, but the direction of rotation is opposite to that of the inner planetary gear. The reaction arm can prevent the shell integrated with the circumferential gear from rotating, and the planetary gear rotates around the sun gear to drive the square head to rotate, thereby outputting torque.


  • Features

The torque multiplier and the reaction arm support claw (reaction foot) socket wrench are composed, which can easily and quickly complete the tightening and disassembly of bolts and nuts.




  • Parameters

Model

Applicable bolt diameter

Applicable bolts
Opposite size

D

H

H

Input party

Output square shaft

Transmission ratio

Torque value

Weight

MDS-15

M20-M30

S30-S46

85

130

34

12.7

25

4.8:1

1500

2.5

MDS-20

M22-M36

S32-S55

78

158

78

12.7

25

17∶1

2000

4

MDS-35

M30-M45

S46-S70

86

184

91

12.7

30

20∶1

3500

5.5

MDS-55

M36-M52

S55-S80

96

190

91

12.7

35

23∶1

5500

7.5

MDS-75

M42-M60

S65-S90

113

201

103

12.7

40

25∶1

7500

10

MDS-100

M52-M72

S80-S105

134

285

79.5

12.7

50

67∶1

10000

17

MDS-150

M60-M80

S90-S115

146

305

97

12.7

55

74∶1

15000

25

MDS-200

M72-M95

S105-S135

146

325

108

12.7

60

96∶1

20000

30
