Split hydraulic puller is an ideal new tool to replace traditional puller. Convenient operation, labor-saving, not restricted by site, compact structure, flexible use, suitable for factories and repair places.
Split hydraulic puller is a kind of puller which uses manual or electric oil pump as the power through the transmission of high pressure oil pipe to push the big piston of the puller forward through the hook claw to hook the unloaded object and bear the reaction force to realize the function of pulling and unloading.
|
Model |
YLDC-50T |
YLDC-100T |
YLDC-150T |
YLDC-200T |
YLDC-320T |
YLDC-500T |
|
Lifting force/T |
50 |
100 |
150 |
200 |
320 |
500 |
|
Work pressure/MPA |
60 |
60 |
60 |
60 |
60 |
60 |
|
Pull and unload range/mm |
500 |
500 |
500 |
600 |
600 |
600 |
|
Ejection stroke/mm |
150 |
200 |
200 |
200 |
200 |
200 |
