Spiral three-jaw puller

By moving the handle back and forth, the supporting teeth pushes the ratchet wheel to rotate intermittently, so that the gear drives the screw rod to rotate, so that the lifting sleeve can be raised or lowered to achieve the purpose of lifting and pulling.


  • Features

This product is suitable for railway vehicle maintenance, mechanical installation, mining and construction engineering support and general lifting and lowering of heavy objects. It can also disassemble belt pulleys, gears, bearings and other workpieces in various mechanical equipment. When working, it is used for linear static tension, which is convenient and labor-saving, stable performance, reasonable structure, convenient to carry, and is widely applicable to mobile operations.


  • Parameters

Model

Lifting force/f

Work plan/mm

height/mm

Effective diameter
 of pull claw/mm

Handle operating
 force/kg

QH3

3

110

220

20-240

10

QH5

5

130

250

20-280

16

QH8

8

140

260

25-390

25

QH10

10

150

280

35-400

28

QH16

16

180

320

40-420

40

QH20

20

180

325

50-450

50

QH32

32

200

400

100-500

60

QH50

50

250

452

100-550

80

QH100

100

200

450

150-600

60
