Hydraulic three-jaw puller

Estimate the pulling force required for pulling and unloading, and select the hydraulic puller corresponding to the tonnage so that it does not exceed the rated capacity. The puller can be used as a jack, as long as the pull claw is removed. The refueling hole is set on the outer jacket when refueling is needed. When lifting, you should pay attention to the stroke height of the puller. When the specified height is not pressed, it means that the rated height has been reached and the lifting should be stopped. Personnel should be responsible for general failure or maintenance.


  • Features

It is suitable for machinery, metallurgy, mining, railway, oil field and other industries. When repairing and maintaining equipment, jacking up heavy objects, pulling and unloading discs, bearings and other parts, when repairing and maintaining equipment, topping Used for lifting objects, pulling and unloading discs, bearings and other parts. Because it is easy to carry and reliable in use, it is especially suitable for field or mobile operations.


  • Parameters

model

Lifting force/f

work plan/mm

height/mm

Effective diameter
of pull claw/mm

ZH1.5

1.5

70

130

20-180

ZH3

3

100

170

20-240

ZH5

5

110

170

25-300

ZH8

8

140

240

35-350

ZH10

10

140

240

40-380

ZH16

16

160

250

50-400

ZH20

20

170

260

50-450

ZH32

32

180

270

100-500

ZH50

50

190

280

150-500

ZH100

100

200

290

150-600
