2/3 claws are shared, suitable for different places. Detachable handle and 360 pressure direction design, easy to use in confined spaces. It is widely used in the mechanical maintenance department of metallurgy, mining, textile, papermaking, petrochemical, chemical, electric power, industrial mining and other fields, as well as the manufacture of mechanical appliances to remove gears, bushings, pulleys, etc.
The elastic thimble design can accurately locate the center. Both the claw hook and the claw hook frame are made of high-strength alloy steel, which is not easy to deform. The hydraulic cylinder adopts solid steel integral processing design, fast positioning adjustment nut design, saving time and effort.
|
Model |
HHL-5 |
HHL-10 |
HHL-20 |
HHL-30 |
HHL-50 |
|
|
Contribute/T |
5 |
10 |
20 |
30 |
50 |
|
|
Zhang distance/mm |
50-200 |
50-250 |
100-350 |
150-400 |
200-500 |
|
|
Pitch/mm |
140 |
170 |
205 |
220 |
250 |
|
|
stroke/mm |
50 |
60 |
70 |
70 |
60 |
|
|
Main body |
E |
45 |
56 |
78 |
90 |
114 |
|
F |
23 |
26 |
33 |
38 |
48 |
|
|
G |
106 |
97 |
105 |
103 |
117 |
|
|
Hook end |
A |
12.5 |
14 |
21 |
26 |
25 |
|
B |
22.5 |
30 |
33.5 |
36 |
46 |
|
|
C |
26 |
30 |
33 |
35 |
40 |
|
|
Total Weight/kg |
7.6 |
10.1 |
34.2 |
24.2 |
42.9 |
|
|
Package dimensions/cm |
42×29×9 |
43×33×11 |
48×20×18 |
48×20×18 |
52×25×22 |
|
