Heavy electric pipe bender

The pipe bender for bending special-shaped low-pressure fluid conveying pipes under cold conditions can bend in any direction,The bending angle can reach 90 degrees, the structure of this machine is simple, the operation is convenient, the curved arc surface is smooth, and there will be no deformation and wrinkles;

  • Features
Widely used in construction, chemical, plumbing, petroleum, coal and other units to provide an ideal pipe bending tool;
  • Parameters

Model

Bend range

Bending radius

Elbow wall thickness

Maximum thrust of cylinder

WYQ-60

Φ22-60

4×Pipe diameter

≤4.5

100

WYQ-76

Φ22-76

4×Pipe diameter

≤6

300

WYQ-108

Φ27-108

4×Pipe diameter

≤10

400

WYQ-159

Φ76-159

4×Pipe diameter

≤12

500
