Single mast aluminum lifting platform

1. Single set of high-strength aluminum alloy mast lifting platform, light weight, good maneuverability, suitable for single operation.

2. The guide wheel device between the masts can lift and balance freely.

3. The structure is compact, the size of the dynamic transmission state is small, and it can enter the car of the general elevator and can smoothly pass through the door hole and narrow passage.

4. The double-protected outrigger structure makes it easy to work and can be lifted close to the working surface. It can be made into an explosion-proof aerial work platform according to needs, which is suitable for ascending operations in places where welding resistance is required such as petroleum and natural gas.



  • Parameters

Model

Platform height(m)

Maximum operating height of platform(m)

Rated load(kg)

Platform size(m)

voltagev/HZ

power(KW)

quality(KG)

Dimensions
Length*width*height (m)

GTWY4-100

4

5.7

125

0.64×0.58

AC220/50HZ

0.75

250

1.2×0.82×1.62

GTWY6-100

6

7.7

280

1.2×0.82×1.62

GTWY8-100

8

9.7

300

1.3×0.82×2

GTWY9-100

9

10.7

320

1.4×0.86×2

GTWY10-100

10

11.8

350

1.4×0.86×2
