Manual hydraulic crimping tool

The open C-shaped crimping connector is convenient for putting cables and crimping dies, and has a large crimping capacity. Once the crimping operation is completed, the pressure is automatically released. Avoid forming bad blank holders.


  • Features

Lightweight design, convenient and labor-saving operation, manual pressure relief reset. Even in an inconvenient operating environment, the same operation can be successfully completed through the rotary compression joint. The two-stage hydraulic system design ensures that the crimping can be completed quickly with less force. Steel carrying case packaging, storage tools and accessories.


  • Parameters

Model

HHY-300G

HHY-400D

HHY-400E

HHY-400u

HHY-510

Contribute

6.5T

12T

12T

12T

12T

stroke

17mm

32mm

42mm

20mm

38mm

Crimping range

16-300mm²

16-400mm²

16-400mm²

16-400mm²

16-400mm²

Mold type

Hexagonal

Hexagonal

Hexagonal

Hexagonal

Hexagonal

Configuration mode/mm²

162535
50
7095
120
150185240300

162535
50
7095
120
150185240300400

162535
50
7095
120
150185240300400

162535
50
7095
120
150185240300400

162535
50
7095
120
150185240300400

Total Weight

9kg

11.9kg

12.1kg

9.3kg

11.9kg

Package dimensions

610×210×110mm

610*210*110mm

610*210*110mm

610*210*110mm

770×230×130mm


Model

HHY-430

HHY-35

HHY-400

HHY-400B

HHY-400C

Contribute

11T

11T

12T

12T

12T

stroke

32mm

32mm

30mm

41mm

32mm

Crimping range

16-400mm²

16-400mm²

16-400mm²

16-400mm²

16-400mm²

Mold type

Hexagonal

Hexagonal

Hexagonal

Hexagonal

Hexagonal

Configuration mode/mm²

162535
50
7095
120
150185240300400

162535
50
7095
120
150185240300400

162535
50
7095
120
150185240300400

162535
50
7095
120
150185240300400

162535
50
7095
120
150185240300400

Total Weight

11kg

10.9kg

10kg

11.5kg

11.3kg

Package dimensions

770×230×130mm

770×140×225mm

560×130×140mm

770×135×240mm

770×230×130mm


Model

HHY-300D

HHY-300B

HHY-300

HHY-300C

HHY-300E

Contribute

8t

12T

12t

12T

12T

stroke

13mm

18mm

17mm

26mm

22mm

Crimping range

16-300mm²

16-300mm²

16-400mm²

16-300mm²

16-300mm²

Mold type

Hexagonal

Hexagonal

Hexagonal

Hexagonal

Hexagonal

Configuration mode/mm²

162535
50
7095
120
150185240300

162535
50
7095
120
150185240300

162535
50
7095
120
150185240300

162535
50
7095
120
150185240300

162535
50
7095
120
150185240300

Total Weight

7.7kg

8.4kg

9.5kg

11kg

7.4kg

Package dimensions

540×240×140mm

540×120×240mm

540×120×240mm

770×240×130mm

540×120×240mm



Model

HHY-150

HHY-400A

HHY-300A

HHY-240B

HHY-240A

HHY-120A

HHY-70A

Contribute

12T

16t

11T

12T

10T

8t

7T

stroke

18mm

20mm

18mm

19MM

15.5mm

15.5mm

10mm

Crimping range

14-150mm²

16-400mm²

10-300mm²

16-240mm²

10-240mm²

10-120mm²

6-70mm²

Mold type

Point pressure

Hexagonal

Hexagonal

Hexagonal

Hexagonal

Hexagonal

Hexagonal

Configuration mode/mm²

142238
60
7080
100
150

162535
50
7095
120
150185240300400

162535
50
7095
120
150185240300

162535
50
7095
120
150185240

162535
50
7095
120
150185240

162535
50
7095
120

61016
25
3550
70

Total Weight

6.7kg

15kg

6.4kg

9.3KG

6.3kg

4.5kg

2.8kg

Package dimensions

560×140×230mm

625×110×240mm

533×206×102mm

640×140×160mm

533×206×102mm

430×190×90mm

355×173×83mm
