Mechanical cable cutter

The cable cutter is a special scissors, which is designed by using the principle of "leverage principle" and "pressure is inversely proportional to force area". Because the strength and convenience of ordinary scissors cannot fully meet the work needs of users, ratchet cable cutters, manual hydraulic scissors, and electro-hydraulic scissors have been developed.

1. The ratchet cable cutter is suitable for telephone lines and high-voltage PE and LV cables, which can be cut quickly and work efficiently.

2. The blade of the ratchet cable cutter is processed by high-carbon steel tungsten alloy steel, which is sturdy and durable, and has a long life.

3. The ratchet structure design makes cutting faster

4. The handle is equipped with a rubber non-slip sleeve

  • Features

It is widely used in important industries and infrastructure construction fields such as electric power, mining, construction, marine engineering, bridge construction, aviation, steel, shipbuilding, ports, petrochemicals, etc.

  • Parameters

Model

Shear range

Package dimensions

Total Weight

HHD-13J

Cut the steel-cored aluminum stranded wire below 720mm² and the steel stranded wire below 150mm²

345×125×46

1.95

HHD-30J

Cut the steel-cored aluminum stranded wire below 620mm² and the steel stranded wire below 150mm²

524×328×59

7.5

HHD-40J

Cut steel and aluminum cables below 300mm²/cut 1000 pairs of communication cables

380×160×50

1.2

HHD-52J

Cut copper and aluminum wires and armored cables below 500mm²

397×165×54

3.2

HHD-75J

Cut 3×120mm² or less than Φ75mm copper aluminum wire and armored cable
Cut 3600 pairs of communication cables

460×240×40

3.7

HHD-95J

Cut 3×185mm² or less than Φ95mm copper aluminum wire and armored cable

480×290×40

5.2

HHD-100J

Cut 3×300mm² or Φ100mm copper and aluminum wires and armored cables

530×310×50

6.5

HHD-130J

Cut 3×300mm² or Φ100mm copper and aluminum wires and armored cables

560×370×55

9.3
