Slitting machine hydraulic nut

The working principle of YL-Nut hydraulic nut is to use a simple “T-handle” to rotate the “pressurizing screw” to press into the “pressurizing piston”. At this time, the sealing hydraulic pressure is increased to squeeze out the "ring piston" to tighten the rotating tool. At the same time, you can confirm whether the scale of the "thrust indicator" is the set thrust value.


  • Features

The surface is knurled, the weight is light, and the special wrench is used for easy installation and removal. The axial locking force is large, and the blades are firmly locked on the slitting machine without deformation due to axial pressure. Reduce the wear of the blade, extend the life of the blade, shorten the tool setting time, improve the efficiency of the equipment, and the burr of the slitting plate is small. No need to add oil, stable axial force, good sealing performance, no oil leakage.


  • Parameters

Model

Thread

Outer diameter

Thickness

Pressure ring
(inner diameter + outer diameter)

YL-Nut100

M100×2

Φ160

45

120×140

YL-Nut110

M110×2

Φ170

48

130×150

YL-Nut120

M120×2

Φ180

45

140×155

YL-Nut130

M130×2

Φ185

50

150×170

YL-Nut140

M140×2

Φ225

53

180×200

YL-Nut150

M150×2

Φ240

53

180×200

YL-Nut160

M160×2

Φ250

53

190×210

YL-Nut170

M170×2

Φ280

60

200×220

YL-Nut180

M180×2

Φ285

60

230×250

YL-Nut190

M190×2

Φ285

60

230×250

YL-Nut200

M200×2

Φ285

60

250×270

YL-Nut210

M210×2

Φ295

65

250×270

YL-Nut220

M220×2

Φ300

65

250×270

YL-Nut230

M230×2

Φ320

65

280×280

YL-Nut240

M240×2

Φ330

65

280×300

YL-Nut250

TR250×2

Φ340

65

280×300

YL-Nut260

TR260×2

Φ350

65

300×330

YL-Nut270

TR270×2

Φ360

65

300×330
