Microcomputer bearing heater YL series

The coil of the microcomputer bearing heater generates a large amount of current inside the workpiece through the magnetic field generated by electromagnetic induction, which is converted into heat. The high voltage and low current of the heater pass through the induction coil with a large number of turns, and low voltage and high current are generated on the workpiece


  • Features

Apply a layer of general bearing grease to the contact surface of the horizontal and vertical yoke, which not only reduces the magnetic field loss, but also significantly reduces the noise level


  • Parameters

Model

YL-1

YL-2

YL-3

YL-4

YL-5

YL-6

YL-7

YL-8

YL-9

YL-10

Equipment  power

1KVA

3.6KVA

3.6KVA

8KVA

12KVA

24KVA

12KVA

24KVA

40KVA

95KVA

Voltage

220V

220V

220V

380V(Two-phase)

380V(Two-phase)

380V(Two-phase)

380V(Two-phase)

380V(Two-phase)

380V(Two-phase)

380V(Two-phase)

Rotating arm

/

/

Have

Have

Have

Have

Have

/

/

/

Bearing weight

15

35

35

125

250

350

550

600

1250

As required

Bearing inner diameter

30-100

30-160

30-160

50-250

70-400

75-600

75-400

85-600

85-800

145-1200

Bearing outer diameter

150

<340

<340

480

700

700

920

900

1400

2500

Bearing width

60

150

150

200

265

265

350

400

420

700

Temperature

300℃

Magnetic probe

Have

Temperature digital display

Have

Way to control

Manual / time control / temperature control

Time limit

0-99min

Time digital display

Have

Voice prompt

Have




  • Programme

YL-1

YL-2


YL-3

YL-4

YL-5

YL-6
