Large tonnage hydraulic jack

One-piece retaining ring design prevents the plunger from overstretching beyond the stroke;

Standard hard deep groove saddle, which can be tilted to adapt to uneven components;

Double action can quickly retract and improve work efficiency;

The protection valve protects the jack from damage during system failure;

The dustproof ring reduces pollution and extends the service life of the jack;

The stroke and aperture can be customized according to user needs;

The dustproof ring design can reduce pollution and extend the service life;

  • Features

It has the characteristics of large output power, light weight, and long-distance operation in any space position.

Used in various industries such as transportation, railways, bridges, shipbuilding, construction, factories and mines,

In recent years, it has been widely used in foundation settlement tests and static piles.

The jacking capacity is large, with the anti-overload protection device, and optional saddle to reduce the risk of side pressure.


  • Parameters


Model

Tonnage

Stroke

Body height

Stretch height

Cylinder outer diameter

Piston rod diameter

Inner diameter of oil cylinder

Weight

DYG50-100

50

100

225

325

127

70

100

35

DYG50-200

200

325

525

46

DYG50-300

300

425

725

133

48

DYG50-500

500

625

1125

140

63

DYG100-100

100

100

250

350

180

100

140

58

DYG100-200

200

350

550

78

DYG100-300

300

450

750

194

96

DYG100-500

500

650

1150

130

DYG150-100

150

100

260

360

219

125

180

58

DYG150-200

200

360

560

230

86

DYG150-300

300

460

760

103

DYG150-500

500

660

1160

255

DYG200-100

200

100

285

385

270

145

200

96

DYG200-200

200

385

585

116

DYG200-300

300

485

785

161

DYG200-500

500

685

1185

221

DYG320-100

320

100

310

410

325

180

250

196

DYG320-200

200

410

610

258

DYG320-300

300

510

810

311

DYG320-500

500

710

1210

456

DYG400-100

400

100

360

460

400

230

300

198

DYG400-200

200

460

660

264

DYG400-300

300

560

860

367

DYG400-500

500

760

1260

456

DYG500-100

500

100

375

475

425

250

320

323

DYG500-200

200

475

675

420

DYG500-300

300

575

875

581

DYG500-500

500

775

1275

599

DYG630-100

630

100

420

520

500

270

360

560

DYG630-200

200

520

720

696

DYG630-300

300

620

920

898

DYG630-500

500

820

1320

1250

DYG800-100

800

100

530

630

560

320

400

896

DYG800-200

200

630

830

1040

DYG800-300

300

730

1030

1380

DYG800-500

500

930

1430

1520

DYG1000-100

1000

100

560

660

610

350

450

1286

DYG1000-200

200

620

820

1332

DYG1000-300

300

760

1060

1663

DYG2000-200

2000

200

780

980

890

500

650

/


  • Programme




Conventional electric hydraulic package



Features: The double-acting large-tonnage jack has large output force, light weight, strong carrying capacity,

                 and can be operated remotely in any space position

Uses: used in various industries such as transportation, railways, bridges, shipbuilding, construction, factories and mines






Electric hydraulic synchronous jack (two synchronous)


Features: The double-acting large-tonnage jack has large output force, light weight, strong carrying capacity, and can be

                 operated remotely in any space position

Uses: used in transportation, railways, bridges, shipbuilding, construction, mining and other industries






Electro-hydraulic synchronous jack (four synchronous)



Features: The double-acting large-tonnage jack has large output force, light weight, strong carrying capacity, and can be

                 operated remotely in any space position

Uses: used in various industries such as transportation, railways, bridges, shipbuilding, construction, factories and mines
